Bosch Pro Series PIR w/Anti-Mask,ISC-PDL1-WA18G

• 18 m x 25 m (60 ft x 80 ft) standard coverage, 8 m x 10 m (25 ft x 33 ft) selectable short range coverage
• EN50131-2-4 Grade 3 compliant
• Sensor data fusion technology
• Tri-focus optics technology
• Range adaptive radar
• MANTIS anti-mask
• Active white light suppression
• Dynamic temperature compensation
• Remote walk test
• Alarm memory
• Draft and insect immunity

Power Requirements
Voltage (Operating):	9 VDC to 15 VDC
Current (Maximum):	< 26 mA with alarm, trouble, and LEDs active.
Current (Standby):	18 mA at 12 VDC
Outputs for All Models
Tamper:	Normally-closed (NC) contacts (with cover on) rated at 25 VDC, 125 mA maximum.Connect tamper circuit to 24-hour protection circuit.
Trouble:	Solid state relay normally-closed (NC) contacts.
Outputs for ISC-PDL1-WA18G and ISC-PDL1-WA18H
Alarm Relay:	Solid state relay, normally-closed (NC) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
Outputs for ISC-PDL1-WA18GB
Alarm Relay:	Solid state relay, normally-open (NO) contacts, power supervised.3 W, 125 mA, 25 VDC, resistance < 10 Ω.
Enclosure Design
Color:	White
Dimensions:	127 mm x 69 mm x 58 mm(5 in. x 2.75 in. x 2.25 in.)
Material:	High-impact ABS plastic

Indicators
Alarm Indicator:	Blue LED for TriTech+ alarms
Yellow LED for microwave detection
Red LED for PIR detection
Zones
Zones:	86
Relative Humidity:	0 to 95%, non-condensing
Temperature (Operating and Storage):	-30°C to +55°C (-22°F to +130°F)For AFNOR certificated installations,-10°C to +55°C (+14°F to +130°F)For UL Certificated installations, 0°C to +49°C (+32°F to +120°F)
Environmental Rating (EN 50130-5):	Class II
Protection Rating (EN 60529, EN 50102):	IP 41, IK04
